TLP785(BLL-TP6F(C

Manufacturer Part Number: TLP785(BLL-TP6F(C	Part of Description: Transistor Output Optocouplers
Manufacturer / Brand: Toshiba	Lead Free Status / RoHS Status: Lead free / RoHS Compliant
Ship From: HHK/Shen Zhen	Shipment Way: DHL/Fedex/TNT/UPS
Datasheets: TLP785(BLL-TP6F(C Datasheet (PDF)

Product parameters

Manufacturer:	Toshiba
Product Category:	Transistor Output Optocouplers
Mounting Style:	Through Hole
Package / Case:	DIP-4
Number of Channels:	1 Channel
Isolation Voltage:	5000 Vrms
Output Type:	NPN Phototransistor
If – Forward Current:	16 mA
Vf – Forward Voltage:	1.3 V
Maximum Collector Emitter Voltage:	80 V
Maximum Collector Current:	10 mA
Maximum Collector Emitter Saturation Voltage:	400 mV
Rise Time:	2 us
Fall Time:	3 us
Vr – Reverse Voltage:	5 V
Pd – Power Dissipation:	240 mW
Minimum Operating Temperature:	– 55 C
Maximum Operating Temperature:	+ 110 C
Series:	TLP785
Brand:	Toshiba
Collector-Emitter Breakdown Voltage:	80 V
Configuration:	1 Channel
Description/Function:	–
Height:	3.5 mm
Length:	4.6 mm
Product Type:	Transistor Output Optocouplers
Reference Voltage:	–
Subcategory:	Optocouplers
Width:	6.5 mm
Unit Weight:	0.009171 oz
